00 // HERO
PKT 00:00:00
33.6844° N · 73.0479° E — Islamabad, Pakistan
▶ CURRENTLY: Advanced PCB fabrication on Carvera CNC
Hardware & Embedded Systems Engineer
IBRAR AHMAD
PCB Designer · Firmware Dev · EEG Hardware

Ibrar Ahmad portrait
SCROLL TO EXPLORE
01 //

TECH STACK

ibrar@dev:~/portfolio
ibrar@dev:~/portfolio$ _
02 //

PROJECT SHOWCASE

DermScope REVIVE PCB Top DermScope REVIVE PCB Bottom
Top View
VIEW INTERACTIVE PCB →
PCB DESIGN PRJ-2026-PCB-0005
2026 Revive Medical Technology
DERMSCOPE REVIVE — Carrier PCB

Advanced high-speed carrier PCB for handheld dermatology imaging. 4-layer ENIG board hosting INVENSOM-6UL SOM (NXP i.MX6UL Cortex-A7), MIPI CSI 4-lane camera pipeline, MIPI DSI 4-lane 2K display, multi-polarization dermoscopy optics, and full wireless connectivity. 90×62mm · Medical-grade · RoHS compliant.

4 LAYERS 90×62mm NXP iMX6UL MIPI CSI/DSI ENIG 100Ω DIFF 4G LTE Wi-Fi + BT GPS/GNSS TP4056
VIEW INTERACTIVE PCB GITHUB REPO
OPEN CV →
DOCUMENTATION PRJ-2026-DOC-0003
2026 Personal · Dual Language
PROFESSIONAL CV — LaTeX

Dual-language curriculum vitae (English & Indonesian) built with Awesome-CV LaTeX template. Compiled via XeLaTeX for full Unicode support and deployed via GitHub Pages.

LaTeX / XeLaTeX Awesome-CV English + Indonesian GitHub Pages PDF Output
VIEW CV ONLINE GITHUB REPO
0x00
FIRMWARE COMING SOON
IN DEVELOPMENT
2026 TWS Earbud Platform
TWS AUDIO EARBUD PLATFORM

Low-power true-wireless stereo earbud firmware and audio control stack. Includes Bluetooth LE audio pairing, audio codec control, and ANC-ready signal path for compact wearable products.

Bluetooth LE Audio TWS Pairing nRF5340 Audio Codec ANC Ready
IOT GATEWAY COMING SOON
IN DEVELOPMENT
2026 Industrial IoT
INDUSTRIAL IoT GATEWAY PCB

Multi-protocol industrial gateway supporting MQTT, AMQP, OPC-UA, 4G LTE and Ethernet connectivity. Designed for harsh environments with -40°C to +85°C operating range.

4G LTE Ethernet MQTT / OPC-UA Modbus RTU DIN Rail
03 //

ABOUT & CONTACT

// ABOUT ME

Ibrar Ahmad profile
Embedded Hardware Builder
GitHub contribution heatmap for hiibrarahmad

// GET IN TOUCH
